Bơm bánh răng

Model

Displancement
c.c/rev
(in3/rev)

Max. Pressure kgf/cm2(psi)

Continuous
Pressure
kgf/cm2(psi)

Input Speed
Range(rpm)

Port Size(PT)

Weight
kg(lb)

Max.

Min.

Outlet

Inlet

HP1-01

1.2(0.07)

250(3500)

210(3000)

4000

600

Please refer to "Inlet & Outlet Configurations"

1.0(2.2)

HP1-03

3.0(0.18)

1.1(2.4)

HP1-05

5.0(0.31)

1.2(2.6)

HP1-07

7.8(0.48)

1.4(3.1)

HP1-10

10.0(0.61)

210(3000)

180(2500)

1.5(3.3)

HP2-04

4.0(.024)

250(3500)

210(3000)

2.1(4.6)

HP2-06

6.2(0.38)

2.2(4.8)

HP2-08

8.4(0.51)

2.4(5.3)

HP2-11

11.0(0.67)

2.5(5.5)

HP2-14

14.3(0.87)

2.7(5.9)

HP2-16

16.5(1.01)

2.8(6.2)

HP2-19

19.2(1.17)

210(3000)

180(2500)

3.0(6.6)

HP2-22

22.5(1.37)

190(2700)

160(2275)

3.1(6.8)

HP2-25

25.0(1.53)

190(2700)

160(2275)

3.2(7.0)
